Heavy-Duty Rubber Pneumatic Launching Inflatable Roller Bags Marine Airbags Lifting Air Lift Bags
Description
Inflatable marine airbags are designed to provide buoyancy and lift heavy objects or vessels in the water. They are made from durable and strong materials that are capable of withstanding tough marine environments. Marine airbags are commonly used in the shipping and shipbuilding industry to launch or recover vessels. These airbags can provide a safer, more cost-effective and efficient alternative to traditional launch and recovery methods.
Inflatable marine airbags come in different sizes and shapes to cater to the specific needs of the marine industry. They are available in diameters ranging from several meters to tens of meters, and they can be customized according to specific requirements. These airbags are designed to be inflated with compressed air through a valve system. As the airbag inflates, it lifts the vessel from the water and provides buoyancy. Once the vessel is safely lifted, the airbags can be deflated and reused for future operations.
Overall, inflatable marine airbags are an essential tool for the shipping and shipbuilding industry. They provide a safe, efficient, and economical solution for vessel launching and recovery, and they are a testament to the power of innovative engineering solutions.
Specifications
| Item | Description |
| Product Name | Heavy-Duty Rubber Pneumatic Launching Inflatable Roller Bags Marine Airbags Lifting Air Lift Bags |
| Material | 100% Top-Grade Natural Rubber |
| Type | Inflatable, Lifting, Roller, Launching |
| Diameter | 0.5m-3.0m, or As Request |
| Length | 1.0m-28.0m, or As Request |
| Working Pressure | 0.05-0.25 mpa |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer -Standard Wooden Pallets. |
| Color | Black |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| Applications | Ship launching and docking Marine salvaging and wreck removal Dry-docking and ship repairs Bridge construction and repair Jetty and pier construction Heavy machinery and equipment transportation on water Marine vessel lifting and launching |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Durability
Marine airbags are made from tough and resilient materials that can withstand harsh marine environments.
Versatility
Airbags come in various shapes and sizes to accommodate different vessel types and sizes. They can also be customized according to specific requirements.
Cost-effective
Marine airbags offer a cost-effective solution for vessel launching and recovery compared to traditional methods.
Reusability
Inflatable marine airbags are reusable and can be used multiple times for various operations.
Buoyancy
These airbags provide buoyancy and lift heavy objects or vessels, which makes them an ideal solution for vessel launching and recovery.
Safety
Airbags offer a safer option for launching and recovering vessels as they reduce the risks of accidents and damage to the vessel. So, they are an essential tool for the maritime industry.
Applications
● Ship launching and drydocking
● Salvage and marine rescue
● Pipeline and cable laying
● Underwater construction
● Bridge building
● Marine transportation
● Flood control and prevention
● Offshore drilling and exploration
● Dredging and excavation.
Advantages
High-quality materials
We use only top-quality materials in our manufacturing process to ensure that our airbags meet the highest standards of safety and durability.
Customizable solutions
We provide customized inflatable marine airbags to suit the unique requirements of our clients and their vessels.
Reliable and consistent delivery
We maintain a consistent level of quality in our production processes and deliver our products on time to ensure the satisfaction of our customers.
Experienced team
Our team of experts in the manufacturing of inflatable marine airbags has many years of experience, which allows them to provide our clients with the best possible products and services.
