Water Testing System Ocean Hydrostatic Load Testing Water Bags for Weight Testing
Description
Load Testing Water Bags are reliable and versatile tools used for conducting load testing and weight load monitoring. These bags are specifically designed to bear heavy loads and simulate the weight of liquids such as water, thereby providing accurate results in various load testing scenarios. Load Testing Water Bags are made from high-quality materials to ensure durability and safety during testing. They are equipped with handles and reinforced eyelets for easy handling and attachment. These bags are available in different capacities, ranging from small to large, to accommodate different load testing requirements.
In addition to load testing, these water bags can also be used for weight load monitoring during lifting operations. They can be used in industries such as construction, offshore, shipping, and transportation. Load Testing Water Bags offer numerous advantages over conventional methods of load testing. They are cost-effective, portable, and easy to use. Their flexibility allows for testing in a variety of environments, including confined spaces and remote locations. They can be quickly inflated and filled with water, allowing for efficient and accurate load testing.
In conclusion, Load Testing Water Bags are essential tools for load testing and weight load monitoring. They provide a safe and reliable solution for assessing the capacity and strength of structures, equipment, and lifting operations.
Specifications
| Application | Proof Load Testing, Offshore Load Testing, Structural Load Testing, Ship Load Testing, Industrial Equipment Testing, Research and Development. |
| Content | 100% POLYVINYL CHLORIDE |
| Phthalate | 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65, CPSIA and REACH) |
| Backing Material Size | 1.8/2.0 MM X 1.55M, thickness produced as per your request. |
| Standard | LEEA 051 |
| Weight | 37.1 oz square yard/ 1450 +- 50 GSM |
| Special | UV Resistant |
| 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65, CPSIA and REACH) | |
| BPA Free / Tris Free / Formaldehyde Free | |
| Does not contain Conflict Minerals | |
| Care Instructions | Rinse with fresh water and air dry |
| Do not store with seawater and keep away from heat sources | |
| Available sizes | 5000 kg |
| 8,000 kg | |
| 1,0000 kg | |
| 15,000 kg | |
| 20,000 kg | |
| 30,000 kg | |
| 50,000 kg | |
| 100,000 kg | |
| Special sizes could be customized | |
| OEM | Supported |
| MODEL | Weight | Volume | Empty Height (Length) |
Filled Height (Length) |
Max Diam (ø) |
Dry Weight without accessories |
| kg | Liters / m3 | m | m | m | kg | |
| lbs | USG | ft | ft | ft | lbs | |
| HM-1T | 1,000 | 1,000 / 1 | 2.52 | 2.23 | 1.39 | 36 |
| 2,204 | 264 | 8.27 | 7.33 | 4.56 | 80 | |
| HM-2T | 2,000 | 2,000 / 2 | 2.87 | 2.6 | 1.65 | 41 |
| 4,409 | 528 | 9.41 | 8.5 | 5.43 | 90 | |
| HM-3T | 3,000 | 3,000 / 3 | 3.38 | 2.97 | 1.82 | 50 |
| 6,613 | 792 | 11.11 | 9.75 | 6.0 | 110 | |
| HM-4T | 4,000 | 4,000 / 4 | 3.41 | 3.07 | 1.88 | 64 |
| 8,818 | 1,056 | 11.22 | 10.1 | 6.16 | 141 | |
| HM-5T | 5,000 | 5,000 / 5 | 4.14 | 3.52 | 2.13 | 80 |
| 11,023 | 1,320 | 13.60 | 11.58 | 7.0 | 176 | |
| HM-6T | 6,000 | 6,000 / 6 | 4.39 | 3.91 | 2.28 | 86 |
| 13,227 | 1,585 | 14.41 | 12.83 | 7.48 | 189 | |
| HM-8T | 8,000 | 8,000 / 8 | 4.54 | 3.93 | 2.52 | 104 |
| 17,636 | 2,113 | 14.91 | 12.91 | 8.27 | 230 | |
| HM-10T | 10,000 | 10,000 / 10 | 5.18 | 4.49 | 2.70 | 130 |
| 22,046 | 2,641 | 17.0 | 14.75 | 8.90 | 286 | |
| HM-12.5T | 12,500 | 12,500/ 12.5 | 5.43 | 4.62 | 2.86 | 154 |
| 27,558 | 3,302 | 17.91 | 15.16 | 9.39 | 340 | |
| HM-15T | 15,000 | 15,000 / 15 | 6.24 | 5.48 | 2.95 | 159 |
| 33,069 | 3,962 | 20.50 | 18.00 | 9.70 | 350 | |
| HM-20T | 20,000 | 20,000 / 20 | 6.78 | 6. 04 | 3.42 | 224 |
| 44,100 | 5,283 | 22.25 | 19.83 | 11.25 | 492 | |
| HM-25T | 25,000 | 25,000 / 25 | 7.51 | 6.40 | 3.75 | 315 |
| 55,115 | 6,604 | 24.66 | 21.0 | 12.33 | 695 | |
| HM-35T | 35,000 | 35,000 / 35 | 8.07 | 7.11 | 3.91 | 417 |
| 77,161 | 9,246 | 26.50 | 23.33 | 12.83 | 920 | |
| HM-40T | 40,000 | 40,000 / 40 | 8.71 | 7.72 | 4.07 | 440 |
| 88,184 | 10,566 | 28.58 | 25.33 | 13.36 | 970 | |
| HM-50T | 50,000 | 50,000 / 50 | 8.99 | 7.77 | 4.56 | 544 |
| 110,231 | 13,208 | 29.50 | 25.50 | 14.96 | 1200 | |
|
HM-100T |
100,000 | 100,000 / 100 | 11.27 | 10.00 | 5.65 | 952 |
| 220,462 | 26,420 | 37.00 | 32.9 | 18.56 | 2100 |
Features
Capacity
Load testing water bags come in various sizes and capacities to accommodate different load capacities. The capacity of the bag determines the amount of weight it can hold during load testing.
Durability
Load testing water bags are designed to be durable and withstand heavy loads and harsh environments. They are typically made from strong and tear-resistant materials such as PVC or nylon, ensuring they can handle repeated use and exposure to water.
Filling and draining mechanisms
Load testing water bags often feature built-in mechanisms for easy filling and draining of water. This allows for quick setup and dismantling of the load test, as well as efficient water management during the testing process.
Safety features
Load testing water bags are designed with safety in mind. They often have multiple attachment points and sturdy handles to securely hold the bag in place during testing. Additionally, many bags include reinforced seams to prevent leaks and minimize the risk of accidents during load testing.
Applications
● Testing the load capacity of water containers for transportation and storage purposes.
● Assessing the strength and durability of water bags used in military operations.
● Determining the maximum weight that water bags can withstand in disaster relief efforts.
● Evaluating the structural integrity of water bags used in outdoor recreational activities.
● Assessing the weight limit of water bags for use in construction projects.
● Testing the load capacity of water bags for use in agricultural irrigation systems.
● Evaluating the performance of water bags in marine applications, such as floating platforms or buoyancy devices.
Advantages
Extensive Experience
With over 30 years of manufacturing experience, we have honed our expertise in producing Load Test Water Bags to meet the highest industry standards. This experience enables us to deliver reliable and top-quality products consistently.
Specialization
Our factory is dedicated solely to the production of Load Test Water Bags. This specialization allows us to focus on perfecting the design, functionality, and durability of our products to cater specifically to the needs of load testing applications.
Quality Assurance
We have implemented rigorous quality control measures throughout our production process. From sourcing high-quality materials to conducting thorough testing, we ensure that each Load Test Water Bag leaving our factory meets stringent quality standards, providing reliable and accurate load testing results.
Customization Capability
We understand that different load testing requirements may vary. To cater to diverse needs, we offer customization services to tailor our Load Test Water Bags based on specific load capacities, sizes, and other specifications. Our ability to provide customized solutions ensures that our customers receive the most suitable and efficient load testing equipment.
