Marine Rubber Airbag Lifting Airbag Salvage Rubber Airbags for Vessel Relocation
Description
Tugging Marine Rubber Airbag Our Tugging Marine Rubber Airbags are specifically designed for towing and transporting large vessels or structures. With reinforced rubber and fabric layers, these airbags offer superior strength and durability to withstand the stress of continuous tugging operations in tough marine environments.
Hongruntong Marine’s tugging airbags provide excellent buoyancy and balance, ensuring safe and efficient transport of vessels in both calm and rough waters. Their robust construction guarantees a long service life, even under extreme conditions.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Material | NBR |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Rubber Airbag |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Floating Crane Support
Provides buoyancy support for floating crane operations.
Mooring Assistance
Helps stabilize vessels during docking or mooring operations.
Temporary Dry Docking
Provides temporary buoyancy for vessels under repair or maintenance.
Bridge Construction
Used in marine bridge construction for lifting and positioning heavy components.
Offshore Platform Relocation
Ideal for relocating large offshore platforms in offshore oil and gas operations.
Applications
● Large vessel relocation
● Offshore construction support
● Floating platform positioning
Advantages
High Pressure Resistance
Airbags designed to handle high pressure without compromising performance.
Anti Corrosion Properties
Resistant to corrosion from seawater, ensuring longevity and durability.
User Friendly Design
Easy to operate and maintain, even in challenging marine environments.
Stable Performance
Consistent performance under different conditions, including rough seas and extreme weather.
