0.07Mpa Marine Airbag Launching Saltwater Corrosion Proof Puncture Resistant Design
Description
For unique projects like floating docks or submarine launches, Hongruntong Marine delivers bespoke Mega-Airbag Systems with diameters up to 4.0m and custom lengths. Using 3D-scanned hull profiles, we optimize airbag arrays for perfect weight distribution, handling ultra-heavy loads up to 15,000 tons.
Our proprietary Smart Pressure Sync technology ensures balanced lifting, while real-time monitoring prevents overloads. Preferred by defense and offshore industries, this system comes with dedicated engineering support and on-site commissioning. All designs meet MIL-SPEC and class society requirements for mission-critical applications.
Specifications
| Item |
Description |
| Place of Origin |
China |
| Brand Name |
Hongruntong Marine |
| Material |
Industrial-Grade Natural Rubber |
| Diameter |
0.5m-3.0m, or as Request |
| Length |
1.0m-28.0m, or as Request |
| Working Pressure |
0.05-0.25 Mpa |
| Technics |
High Pressure, Overall Winding, Explosion-Proof |
| Use |
Ship Launching and Docking |
| Thickness |
5-13 ply |
| Standard |
Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories |
Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging |
Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords |
Airbag Launching Ship |
| Certificates |
ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ |
1 |
| OEM |
Welcome |
| Diameter |
Working
Pressure
|
Working
Height
|
Bearing Capacity |
| KN/m |
Ton/m |
| D=1.0m |
0.14Mpa |
0.6m |
87.96 |
8.98 |
| 0.5m |
109.96 |
11.22 |
| 0.4m |
131.95 |
13.46 |
| D=1.2m |
0.12Mpa |
0.7m |
94.25 |
9.62 |
| 0.6m |
113.10 |
11.54 |
| 0.5m |
131.95 |
13.46 |
| 0.4m |
150.80 |
15.39 |
| D=1.5m |
0.10Mpa |
0.9m |
94.25 |
9.62 |
| 0.8m |
109.96 |
11.22 |
| 0.7m |
125.66 |
12.82 |
| 0.6m |
141.37 |
14.43 |
| 0.5m |
157.08 |
16.03 |
| D=1.8m |
0.09Mpa |
1.1m |
98.96 |
10.10 |
| 1.0m |
113.10 |
11.54 |
| 0.9m |
127.33 |
12.98 |
| 0.8m |
141.37 |
14.43 |
| 0.7m |
155.51 |
15.87 |
| 0.6m |
169.65 |
17.31 |
| D=2.0m |
0.08Mpa |
1.2m |
100.53 |
10.26 |
| 1.1m |
113.10 |
11.54 |
| 1.0m |
125.66 |
12.82 |
| 0.9m |
138.23 |
14.11 |
| 0.8m |
150.80 |
15.39 |
| 0.7m |
163.36 |
16.67 |
| 0.6m |
175.93 |
17.95 |
| * Other size can be produced follow client's requirements. |
Features
High Load Capacity
Engineered to launch vessels up to 15,000 DWT, with reinforced multi-chamber airbags that evenly distribute weight and prevent hull stress.
Advanced Material Technology
Constructed with a proprietary rubber compound (HRT-800) layered with aramid fibers for superior strength, tear resistance, and long-term durability.
Precision Pressure Control
Equipped with smart valves and digital monitoring to maintain optimal inflation levels (±0.01MPa accuracy) for safe, controlled launches.
Rapid Deployment
Fully operational within 4 hours with quick-connect fittings and portable inflation units, ideal for urgent repairs or remote locations.
Applications
● Coastal shipyards
● Riverfront shipyards
● Landlocked shipyards
● Fishing vessel launching
Advantages
Three Decades of Specialized Production
With continuous manufacturing since 1990, we have perfected the engineering and production of marine airbag systems through thousands of successful launches worldwide.
Proprietary Rubber Formula
Our exclusive HRT-X800 rubber compound combines superior elasticity with exceptional wear resistance, developed through 15 years of dedicated R&D.
Military Grade Reinforcement Structure
The 8-layer construction features high-tensile steel cords rated at 3,200N/mm² strength, arranged in optimal cross-ply orientation for perfect load distribution.
Record Breaking Capacity
We manufacture the world's largest operational airbag systems, with demonstrated capacity to launch vessels up to 18,000 DWT.
FAQ
1. Do you provide training for operators?
Comprehensive training programs are available onsite or at our facility.
2. How do you calculate the required number of airbags?
Our engineers consider vessel weight, dimensions, and launch conditions.
3. Can your systems be used for military vessels?
Yes, we supply MIL-STD-1625 compliant systems to naval forces.
4. What makes your airbags more durable than competitors?
Our proprietary 8-layer construction and HRT-X800 rubber compound provide superior longevity.
