PVC Coated Polyester Fabric Lifting Straps Buoyancy Force Underwater Air Lift Bags for Sale
Description
Underwater Air Lift Bags are essential tools used in marine operations to lift sunken objects or provide buoyancy. These bags are designed to be filled with compressed air and placed beneath submerged objects to create upward force, allowing for safe and efficient recovery operations. With their high-strength, durable construction, Underwater Air Lift Bags can easily withstand the harsh underwater conditions. They are manufactured using materials that are resistant to abrasion, UV radiation, and chemical exposure, ensuring their reliability and performance over extended periods of time.
Underwater Air Lift Bags come in various sizes and lifting capacities, allowing them to handle a wide range of objects, from small items to large structures. They are equipped with industry-standard fittings and valves, allowing for easy inflation and deflation. These bags are not only used for salvage operations but also find applications in underwater construction, pipeline installation, and scientific research. They provide a versatile and cost-effective solution for lifting heavy loads underwater, reducing the need for complex rigging systems and minimizing the risk to divers and other personnel involved in the operation.
In conclusion, Underwater Air Lift Bags are indispensable tools in marine operations, providing a safe and efficient method for lifting sunken objects and providing buoyancy in various underwater applications. Their reliability, strength, and versatility make them an essential component in any underwater operation.
Specifications
| Product Name | Underwater Air Lift Bags, Air Lifting Bags |
| Raw Material | TOP-Grade PVC Coating Fabric |
| Type | Cylindrical, Parachute, Pillow |
| Size | 500kg, 1000kg, 5000kg 10000kg,etc |
| Thickness | 0.4-1.2mm, or as request |
| Color | Yellow,Blue,Black,etc |
| Density | 0.33-0.9g/cm3 |
| Safety Factor | 7:1 |
| Accessories | Valve, Inflatable Tube, Repair Material |
| OEM | Welcome |
| Warranty | 3 Years |
|
Tolerances |
+/- 0.03 on densities +/- 0.2 mm on thickness +/- 0 to +3mm on width +/- 0 to +3mm on length |
| Model | Lifting Capacity | Dimensions | Appr. Weight | |
| Parachute | [kg] | [lbs] | [mm] | [kg] |
| HM-P01 | 200 | 441 | 800 | 5 |
| HM-P02 | 500 | 1,103 | 1,000 | 8 |
| HM-P03 | 1,000 | 2,205 | 1,300 | 11 |
| HM-P04 | 2,000 | 4,410 | 1,600 | 20 |
| HM-P05 | 4,000 | 8,820 | 2,000 | 50 |
| HM-P06 | 6,000 | 13,230 | 2,300 | 66 |
| HM-P07 | 8,000 | 17,640 | 2,500 | 75 |
| HM-P08 | 10,000 | 22,050 | 2,700 | 80 |
| HM-P09 | 15,000 | 33,075 | 3,100 | 110 |
| HM-P10 | 20,000 | 44,100 | 3,400 | 130 |
| HM-P11 | 30,000 | 66,150 | 3,900 | 170 |
| HM-P12 | 50,000 | 110,250 | 4,600 | 220 |
| HM-P13 | 70,000 | 154,350 | 5,200 | 310 |
| HM-P14 | 100,000 | 220,500 | 5,800 | 450 |
| HM-P15 | 150,000 | 330,750 | 6,600 | 660 |
| HM-P16 | 200,000 | 441,000 | 7,300 | 900 |
| *Note: Other sizes can be customized according to the requirements. | ||||
| Model | Buoyancy | Diameter | Length | Appr. Weight | ||
| Cylindrical | [kg] | [lbs] | [mm] | [mm] | [kg] | |
| HM-C01 | 200 | 441 | 500 | 1,000 | 5 | |
| HM-C02 | 500 | 1,103 | 800 | 1,000 | 8 | |
| HM-C03 | 1,000 | 2,205 | 1,000 | 1,500 | 11 | |
| HM-C04 | 2,000 | 4,410 | 1,300 | 1,500 | 20 | |
| HM-C05 | 4,000 | 8,820 | 1,600 | 2,000 | 50 | |
| HM-C06 | 6,000 | 13,230 | 2,000 | 2,000 | 66 | |
| HM-C07 | 8,000 | 17,640 | 2,000 | 2,600 | 75 | |
| HM-C08 | 10,000 | 22,050 | 2,400 | 2,400 | 80 | |
| HM-C09 | 15,000 | 33,075 | 2,600 | 3,000 | 110 | |
| HM-C10 | 20,000 | 44,100 | 3,000 | 3,000 | 130 | |
| HM-C11 | 30,000 | 66,150 | 3,000 | 4,500 | 170 | |
| HM-C12 | 50,000 | 110,250 | 4,000 | 4,000 | 220 | |
| HM-C13 | 70,000 | 154,350 | 4,000 | 5,700 | 310 | |
| HM-C14 | 100,000 | 220,500 | 4,000 | 8,000 | 450 | |
| HM-C15 | 150,000 | 330,750 | 5,000 | 8,000 | 660 | |
| HM-C16 | 200,000 | 441,000 | 5,000 | 10,000 | 900 | |
| *Note: Other sizes can be customized according to the requirements. | ||||||
|
Model |
Capacity |
Length |
Width |
|
|---|---|---|---|---|
|
Pillow |
[kg] |
[lbs] |
[mm] |
[mm] |
| HM-P100 | 100 | 220 | 1,020 | 760 |
| HM-P250 | 250 | 550 | 1,320 | 820 |
| HM-P500 | 500 | 1,100 | 1,300 | 1,200 |
| HM-P1000 | 1,000 | 2,200 | 1,550 | 1,420 |
| HM-P2000 | 2,000 | 4,400 | 1,950 | 1,780 |
| HM-P3000 | 3,000 | 6,600 | 2,900 | 1,950 |
| HM-P5000 | 5,000 | 11,000 | 3,230 | 2,030 |
| *Note: Other sizes can be customized according to the requirements. | ||||
Features
High lifting capacity
Underwater Air Lift Bags are designed to have a high lifting capacity, allowing them to easily lift heavy objects underwater. This showcases the product's professional advantage in handling large-scale underwater operations.
Durable and reliable
These air lift bags are made from high-quality materials that are resistant to wear and tear, ensuring their durability and reliability even in challenging underwater conditions. This highlights the product's professional advantage in providing long-lasting and dependable performance.
Easy to use
Underwater Air Lift Bags are designed with user-friendly features, making them easy to deploy and operate underwater. Their simplicity and convenience demonstrate the product's professional advantage in facilitating efficient and hassle-free underwater lifting operations.
Versatile application
These air lift bags are suitable for a wide range of underwater lifting tasks, including salvage operations, marine construction, and underwater maintenance. Their versatility showcases the product's professional advantage in catering to diverse underwater needs and requirements.
Applications
● Salvage operations
● Offshore oil and gas industry
● Subsea construction projects
● Underwater vehicle recovery
● Underwater equipment deployment/retrieval
● Shipwreck exploration and recovery
● Underwater pipe and cable installation
● Bridge and dam construction/maintenance
● Underwater infrastructure inspection and maintenance
● Underwater construction and repair projects
Advantages
Extensive Manufacturing Experience
With over 30 years of manufacturing experience, we have developed deep expertise in producing high-quality Underwater Air Lift Bags. Our long-standing presence in the industry has enabled us to refine our production processes and deliver superior products to our customers.
Specialized Expertise
Our factory is solely dedicated to the production of Underwater Air Lift Bags, allowing us to focus all our resources and expertise on perfecting this specific product. This specialized knowledge gives us a competitive edge, ensuring that our bags are designed and manufactured to meet the unique requirements of underwater lifting operations.
Quality Assurance
We prioritize quality in every step of our manufacturing process. From sourcing the finest materials to implementing stringent quality control measures, we ensure that our Underwater Air Lift Bags meet the highest standards of durability and reliability. Our commitment to quality assurance guarantees that our customers receive products they can trust.
Customization Capabilities
We understand that different underwater lifting operations may have unique requirements. That's why we offer customization options for our Underwater Air Lift Bags. Whether it's modifying the size, shape, or weight capacity, our team of experts can tailor our products to suit specific customer needs. This flexibility sets us apart and enables us to provide customized solutions that deliver optimal results.
