Ship Launching Landing Operations Repairs Floating Dock Marine Airbags for Ship Launching
Description
Ship launching airbags are innovative and efficient tools used for launching and landing ships. They are made of strong, reinforced rubber layers and are filled with high-pressure air to create a cushioning effect during ship launchings.
These airbags revolutionize the traditional ship launching process by offering numerous advantages. Firstly, they provide a flexible and cost-effective solution, eliminating the need for expensive dry docks or slipways. The ship can be launched directly into the water from the shipyard, saving both time and resources.
Secondly, ship launching airbags are extremely reliable and adaptable. They can withstand high pressure and distribute it evenly throughout the vessel, ensuring a safe and smooth launch. Additionally, their flexible nature allows for easy maneuvering and adjustment according to the ship's shape and weight requirements.
Moreover, these airbags are environmentally friendly as they do not cause pollution or damage to the ship or surrounding environment. They provide an eco-friendly alternative to more traditional methods of ship launching.
In conclusion, ship launching airbags offer a convenient, cost-effective, reliable, and environmentally friendly solution for the launching and landing of ships. Their versatility and efficiency have made them a popular choice in shipbuilding and repair industries worldwide.
Specifications
| Item | Description |
| Product Name | Ship Launching Landing Operations Repairs Floating Dock Marine Airbags for Ship Launching |
| Material | 100% High-Performance Natural Rubber |
| Type | Launching, Docking, Undocking, Lifting, Roller |
| Shape | Cylindrical |
| Diameter | 0.5m-3.0m, or As Request |
| Length | 1.0m-28.0m, or As Request |
| Working Pressure | 0.05-0.25 mpa |
| Hardness | 65 ± 5 shore A |
| Elongation | ≥450 % |
| Surface | Smooth, with protected talc powder |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Color | Black |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| Applications | Ship launching and landing Floating dock construction Salvage and refloating operations Heavy cargo transportation Bridge construction and maintenance Marine structure construction Dockside repairs and maintenance |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
High Load-Bearing Capacity
Ship launching airbags are designed to withstand high pressure and have a remarkable load-bearing capacity. They can support the weight of heavy vessels during the launching process, ensuring a safe and secure operation.
Easy Installation and Portability
These airbags are lightweight and easy to install. They can be quickly inflated, deflated, and transported, making them highly portable and suitable for various shipyards and launching sites.
Excellent Shock Absorption
Ship launching airbags excel in shock absorption capabilities, thanks to their unique design and materials. They effectively absorb and distribute the impact forces, protecting both the ship and the airbag itself from damage during launchings or landings.
Customizable and Versatile
Ship launching airbags come in various sizes and shapes, allowing for customization according to the specific requirements of different vessels. This versatility ensures a perfect fit and optimal performance for each ship, regardless of size or design.
Cost-Effective and Time-Saving
By eliminating the need for expensive dry docks or slipways, ship launching airbags significantly reduce launching and landing costs. Additionally, the quick and straightforward installation process saves valuable time, ensuring efficient operations and increased productivity.
Applications
● Shipyards
● Dry docks
● Port facilities
● Repair and maintenance yards
● Offshore installations
● Naval bases
● Floating docks
● Shipbuilding and repair facilities
● Marine engineering projects
● Vessel launching and landing sites
Advantages
High Quality Materials
We use high quality materials that are specifically designed for ship launching airbags, ensuring their durability and longevity.
Customization
We offer customized airbags to meet the specific needs of our clients, including size, shape, and capacity.
Advanced Production Facilities
Our state-of-the-art production facilities allow us to manufacture airbags efficiently and effectively, ensuring timely delivery of orders.
Experienced Team
We have a team of experienced professionals who are knowledgeable about ship launching airbags and can provide expert advice and support to our clients.
