Home /Products/Marine Rubber Airbags/Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard

Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard

1
MOQ
US$46 - US$2590
Price
Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Marine Rubber Airbags
Standard: ISO14409:2011
Length: 3M-28M Or As Request
Diameter: 0.5M-3.0M Or As Request
Feature: Safe And Environmentally Friendly
Certificate: ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
Reinforcement: Cord Fabric Layer
Outer Layer: Natural Rubber
Inner Layer: Natural Rubber
Material: High Tensile NR
Working Pressure: 0.05-0.25 MPA
Logo: Supported
Warranty: 3 Years
Thickness: 5-13Ply, Or As Request
Package: Pallets, Wooden Cases
Application: Vessel Launching And Docking
OEM: Welcome
Highlight:

marine rubber airbags with warranty

,

airbag launching ship strong pressure resistance

,

stable lifting marine airbags high safety
Basic Infomation
Place of Origin: China
Brand Name: Hongruntong Marine
Certification: ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
Model Number: HM-MRA19
Payment & Shipping Terms
Packaging Details: Wooden Pallets, Wooden Box
Delivery Time: 5-7 Work Days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 3260 Pcs Per Month
Product Description
Marine Rubber Airbags for Ship Launching
Marine Rubber Airbags are premium marine engineering solutions designed for safe and efficient ship launching, vessel retrieval, and heavy marine equipment transport. Constructed with multiple layers of high-strength synthetic tire cord reinforcement embedded within marine-grade natural rubber, these airbags provide superior load capacity, elasticity, and durability.
Product Overview
The internal cord arrangement is optimized for tensile strength and pressure distribution, allowing the airbags to maintain structural stability under dynamic loads and high internal pressures. The outer rubber surface is formulated to resist abrasion, puncture, UV radiation, and seawater corrosion, ensuring long-term performance even under harsh marine environmental conditions.
Marine Rubber Airbags come in diameters ranging from 0.7 meters to 2.5 meters and lengths up to 24 meters, with custom sizes available to meet specific project demands. When inflated, the airbags form a flexible rolling support system that evenly distributes vessel weight and allows smooth movement during launching or landing operations.
Case Study: West African Shipyard
A medium-sized shipyard in West Africa successfully launched a 5,000 DWT container vessel using 16 Hongruntong Marine Rubber Airbags. The vessel measured approximately 110 meters in length with a displacement exceeding 5,000 tons. The engineering team configured airbags with a diameter of 1.7 meters and length of 14 meters arranged along the keel and bilge.
The launch was completed successfully in a single day without structural damage. The shipyard reported reduced preparation time and significant cost savings compared to traditional launching methods. The airbags were subsequently reused for multiple vessel launches, demonstrating long-term durability and operational efficiency.
Technical Specifications
Product NameMarine Rubber Airbags
Material100% High Tensile Natural Rubber
DimensionsDiameter 0.5m - 3.0m, Length 3.0m - 28.0m, or Custom
Working Pressure0.05-0.25 MPA
TechnologyOverall Winding, High Pressure, Explosion Proof
Metal PartsQ355 / SS304 / SS316
StandardISO14409:2011
CertificationsABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS
Service Life20 Years
Warranty36 Months
Load Capacity Specifications
DiameterWorking PressureWorking HeightBearing Capacity KN/mBearing Capacity Ton/m
D=1.0m0.14Mpa0.6m87.968.98
0.5m109.9611.22
0.4m131.9513.46
D=1.2m0.12Mpa0.7m94.259.62
0.6m113.1011.54
0.5m131.9513.46
0.4m150.8015.39
D=1.5m0.10Mpa0.9m94.259.62
0.8m109.9611.22
0.7m125.6612.82
0.6m141.3714.43
0.5m157.0816.03
* Other sizes can be provided following client requirements
Key Features
  • Reinforced Multi Layer Construction: Multiple layers of high-strength synthetic tire cord embedded in premium rubber provide exceptional tensile strength and consistent load distribution
  • Superior Abrasion and Corrosion Resistance: Outer rubber layer resists rolling friction, punctures, UV radiation, and seawater corrosion for long operational life
  • High Elasticity and Shock Absorption: Controlled elasticity absorbs dynamic forces during launching, preventing stress concentration on the hull
  • Easy Handling and Reusability: Portable design with standard air compressor inflation allows for multiple uses and cost-effective operations
Applications
  • Ship Launching: Efficient vessel launching without permanent slipway or dry dock infrastructure
  • Vessel Retrieval and Maintenance: Safe ship retrieval for inspection, maintenance, or repair when dry docks are unavailable
  • Heavy Marine Structure Transport: Moving offshore structures, floating docks, or prefabricated modules along coastal areas
Why Choose Hongruntong Marine
  • Extensive Industry Knowledge: Years of experience in ship launching and marine heavy lifting projects
  • Premium Materials and Manufacturing: High-quality natural rubber reinforced with synthetic tire cords for excellent tensile strength and durability
  • Customized Engineering Solutions: Bespoke airbag configurations tailored to vessel dimensions and operational conditions
  • Comprehensive Technical Support: Professional guidance including selection, layout design, inflation control, and maintenance
Frequently Asked Questions
How do I determine the number of airbags needed for a vessel?
Engineers calculate required airbag quantity based on vessel weight, hull shape, ground slope, and airbag dimensions to ensure even load distribution and safe operation.
Can these airbags be used repeatedly?
Yes, with proper handling, maintenance, and inspection, high-quality marine airbags can be used multiple times for many launching and landing operations.
What equipment is required to inflate the airbags?
Airbags are typically inflated using industrial air compressors with pressure gauges to control the internal pressure accurately for safe operations.
How should airbags be stored to extend lifespan?
After use, airbags should be cleaned, dried, and stored in a shaded, dry area away from sharp objects and direct sunlight to preserve material integrity.
Are Hongruntong Marine Rubber Airbags certified?
Yes, they meet recognized international marine engineering standards including ISO certifications, ensuring safety, reliability, and consistent performance under heavy loads.
Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard 0Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard 1Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard 2Airbag Launching Ship Strong Pressure Resistance Stable Lifting High Safety Standard 3
